5•Service
Doc. 065207-02 9/08 87
Additional Required Items
• #2 Phillips screwdriver
• 1/4-inch open-end wrench (P/N 049452); provided in the ASE 150 Ship Kit
(P/N 066399)
• 2.5-mm hex wrench
• 5/8-in open-end wrench or socket
• Large flathead screwdriver
• Cotton-tipped swabs (or other tool with a soft tip)
• Isopropyl alcohol (IPA) or acetone
Figure 5-19. Static Valve Tools
Piston-Side Seal
Insertion Tool
(P/N 067394)
Inlet-Side Seal
Insertion Tool
(P/N 067395)
Alignment Tool (P/N 068117) and
Push Screw Tool (P/N 068119)
Spacer Tool
(P/N 068118)
Seal Removal Tool
(P/N 068245)
