3.2.5 Installing the Sample Cell in the Cell Holder
The installation procedure is the same for rinse and sample cells. A
sample cell is shown in the photos.
1. Open the cell door.
2. While holding the cell at a
slight angle, position the bottom
end cap under the bottom latch
of the cell holder.
3. Raise the cell so that the bottom
end cap lifts the bottom latch.
4. Straighten the cell until it is
vertical, and then lower it until
the top end cap rests on the top
latch of the cell holder.
5. Close the cell door.
Figure 3-15. Installing a Sample Cell
Top Latch
Bottom
Latch
Bottom Cell
End Cap
