ASE 150 Operator’s Manual
18 Doc. 065207-02 9/08
Monitoring the Progress of a Run
To monitor the progress of a run, press MENU, move the cursor to STATUS (if
necessary), and press
ENTER. The STATUS screen appears (see Figure 2-5).
The
STATUS screen operating parameters are updated in real time.
• STATUS—the current system status. During a run, the status field displays the
following status states (in the order given): Oven Wait, Oven Ready, Load,
Preheat (optional), Fill, Heat, Static, Rinse, Purge, Relief, Unload, and Idle.
• METHOD—the name or number of the current method.
• VOL—the approximate volume of solvent (in mL) delivered by the pump
since the method started running.
• PRESSURE—the current sample cell pressure reading.
• TEMP—the temperature specified in the method.
• TIME—the elapsed time since the method started running.
Figure 2-5. Status Screen Example
STATUS STATIC
METHOD PCB
PRESSURE
TIME
1565PSI
VOL
75mL
2:25
TEMP 100C
