5•Service
Doc. 065207-02 9/08 91
2. Insert the flat end of the seal removal
tool (P/N 068245) into the piston
side of the valve body and push the
inlet-side seal out of the valve body.
3. Pull the seal removal tool out of the
valve body.
4. Insert the flat end of the seal removal
tool into the inlet side of the valve
body and push the seal out of the
piston side of the valve body.
5. Insert the pointed end of the seal
removal tool into the valve body.
Slide the tool between the valve
body and O-ring and pull the O-ring
out of the valve body.
6. Using a cotton-tipped swab (or other tool with a soft tip), thoroughly
clean the inside of the valve body. If necessary, moisten the area with
IPA (isopropyl alcohol) or acetone to remove all debris, sediment, and
precipitates.
Do not use a sharp object to clean the inside of the valve body. Any
scratches on the valve body will prevent a proper seal and cause
leakage.
Inlet-Side Seal
Flat End of
Seal
Removal
Tool
Piston-Side Seal
To Next Page
