DIS DDS 5900 - System Connections

Danish Interpretation Systems User Manual
5.4 Connections
Thischaptergivesanoverview of typical system
connectionsusingtheCU5905CentralUnit:
lthoughtheschematicsaretypicalandareintended
o give a general overview, combinations of the
schematicsarehowevernotonlypossible,butvery
ommonused.
A
t

c

5.4.1 Connecting DC 5980P Units
TheDC5980PConferenceUnitsareconnectedtothe
CU5905 usingEC 6001‐xx Cat5ecables. This isthe
basicconnectionofthesystem.
BothoftheDCS‐LANconnectorsontheCU5905can
beusedforconnectingDC5980PConferenceunits.
Pleaserefertosection‘4.4.1CU5905–DC5980P,one
chain’ for information about the number of units
whichcanbeconnectedusingonechain.
Refertosection‘4.4.2 CU 5905 – DC 5980P, two
hainsc

’whenusingtwochains.

Figure 5.4-A Connecting the DDS 5900 Digital Discussion System.
User Manual DDS 5900
17
