5.4.7 Usin wireless lang ag di tributg u e s ion
The CU 5905 is connected to the DC 5980P
Conference Units using EC 6001‐xx Cat5e cables.
BoththeDCS‐LANconnectorsontheCU5905canbe
DCusedforconnecting 5980PConferenceunits.
In this example two units are configured as
Interpreter Units and DH 6021 Headphone is
connected to the units.  Sound from the Interpreter
Unitscanthenbeheardintheheadphonesconnected
 m eto theChair anandD legateUnits.
A wireless language distribution system like ‘DCS
6000 Digital Infrared Language System’ can then be
connectedtotheAudioOutconnectors(B,CandD),
wherethesourcetotheoutputsareconfiguredasthe
‘Floor’andinterpreterchannels.Refertosection‘
5.6
WebBrowser
’item#8.


Figure 5.4-G Connecting the DDS 5900 Digital Discussion System with interpretation functionality
