Attaching and Detaching the Gimbal
The gimbal is attached to the main body by default. To detach the gimbal, loosen the gimbal ring
1
and
press the release button
2
while rotating the gimbal counter-clockwise
3
.
Refer to the Stabilizer section for more information on the gimbal settings.
Do not detach the gimbal and camera unless necessary. The X9 gimbal and camera do not support
hot-swapping. Make sure to power o the Ronin 4D before attaching or detaching the gimbal and
camera. Make sure the gimbal and camera is mounted rmly.
Camera
The X9 has 14+ stops of dynamic range while the X9-6K camera supports recording at up to 6K/60fps
video and dual native ISO of 800/4000 and the X9-8K camera supports up to 8K/75fps and 800/5000.
The high-quality built-in 9-stop ND lters (ND 2 to ND 512, or ND 0.3 to ND 2.7) can be quickly and
easily switched thanks to the internal motorized system.
3
1
2
To attach the gimbal, align the red marks of the gimbal and the gimbal connector
1
, insert the gimbal,
and rotate the gimbal clockwise
2
. Tighten the gimbal ring
3
after there is a clicking sound, which
indicates the gimbal is locked.
1
2
3
Click
