Interface
Main Body
3.5mm TRS Stereo Input Jack × 1 (supports mic, plug-in power mic, and
line inputs)
3.5mm Stereo Output Jack × 1
USB 3.1 Type-C Data Port × 1
6-pin 1B DC-IN (DC 12-30 V) × 1
Battery Mount Power Port (female) × 1
4D Expansion Plate Data Port (female) × 1
High-Bright Main Monitor Port × 1
Hand Grips Port × 2
Top Handle Port × 1
HDMI Type-A Video Output Port × 1 (Currently supports HDMI 1.4 and
will support HDMI 2.0 in a future rmware update)
X9 Gimbal LiDAR Range Finder/Focus Motor Port × 2
TB50 Battery Mount
Battery Mount Power Port (male) × 1
TB50 Battery Port × 1
4D Video Transmitter
Dimensions 89×21×137 mm
4D Video Transmitter Port
4D Expansion Plate Data Port (male) × 1
SMA Antenna Connector × 4
USB 3.1 Type-C Data Port × 1
Battery Mount Power Port (female) × 1
Battery Mount Power Port (male) × 1
Remote Monitor
Dimensions 216×58×166 mm (Includes monitor cage)
Screen Size 7 inches (Diagonal)
Max Brightness 1500 cd/m²
Screen Resolution 1920×1200
Refresh Rate 60 Hz
Max Battery Life
Approx. 2 hours (Measured at 50% screen brightness with DJI WB37
battery)
Operating Temperature 0° to 40° C (32° to 104° F)
Storage Temperature -20° to 60° C (-4° to 140° F)
Power System DJI WB37 Battery/NP-F Series Battery (Requires NP-F battery adapter)
Remote Monitor Port
3.5mm Stereo Jack × 1
microSD Card Slot × 1 (This port is currently not available. Will support
internal recording in a future rmware update)
HDMI Type-A Video Input Port × 1 (This port is currently not available.
Will support HDMI 1.4 in a future rmware update)
Remote Monitor Expansion Plate High-Speed Port (female) × 1
Remote Monitor Accessory Expansion Port × 1
USB 3.1 Type-C Data Port × 1
Remote Monitor Expansion Port
Remote Monitor Expansion Plate High-Speed Port (male) × 1
HDMI 1.4 Type-A Video Output Port × 1
6-pin 1B DC-IN (DC 6.8-17.6 V) × 1
3G-SDI (Level A) BNC Video Output Port × 1
