DJI Ronin 4D User Manual
72
©
2022 DJI All Rights Reserved.
Single Pulse Width Two kinds of pulses emit in circulation: 5 ns and 33.4 ns.
Max Laser Power 6 W
Main Monitor
Screen Size 5.5 in (diagonal)
Resolution 1920×1080
Refresh Rate 60 Hz
Max Brightness 1000 cd/m²
Screen Rotational LCD touchscreen
Battery
Battery Type TB50 Intelligent Battery
Capacity 4280 mAh
Energy 97.58 Wh
Voltage 22.8 V
Max Charging Voltage 26.1 V
Max Charging Power 180 W
Charging Temperature Range 5° to 40° C (41° to 104° F)
Charging Time Approx. 1.5 hours (with standard 86W power adapter)
DJI O3 Pro Video Transmission
Max Transmission Distance
(Unobstructed, free of
interference.)
20,000 ft (approx. 6 km, FCC-compliant)
Max Transmission Resolution and
Frame Rate
1920×1080 @60fps
Minimum End-to-End Latency
100 ms or 68 ms
(100 ms is measured at 4K/24fps, 68 ms is measured at 4K/60fps.)
Wireless Frequency
Non-DFS frequency band:
2.400-2.483 GHz
5.150-5.250 GHz
5.725-5.850 GHz
DFS Frequency Band:
5.250-5.350 GHz
5.470-5.600 GHz
5.650-5.725 GHz
(Some frequency bands may not be available depending on the legal
policies of the region the monitor was activated in)
Transmitter Power (EIRP)
2.400-2.4835 GHz: ≤33 dBm (FCC); ≤20 dBm (SRRC/CE/MIC)
5.150-5.250 GHz: <23 dBm (FCC/SRRC/MIC)
5.250-5.350 GHz: <30 dBm (FCC); <23 dBm (SRRC/MIC)
5.470-5.600 GHz, 5.650-5.725 GHz: <30 dBm (FCC); <23 dBm (CE/MIC)
5.725-5.850 GHz: <33 dBm (FCC/SRRC); <14 dBm (CE)
Max Bandwidth 40 MHz
Max Bitrate 50 Mbps
