DJI Ronin 4D User Manual
76
©
2022 DJI All Rights Reserved.
Counter Weight and Focus Motor Mounting Hole
Top Handle Mounting Hole
Cutaway View
36.00
26.00
36.00
40.00
4-M3 Depth 5
2-M3 Depth 5Diameter 2 Depth 3
Unit: mm
Unit: mm
72.00
27.00
10.00
6.09
R1.00
68.56
9.42
6.42
5.98
R2
4-M4 Depth 7
3.40
20.00°
1.91 4.28
1.50
