DJI Ronin 4D User Manual
77
©
2022 DJI All Rights Reserved.
135.00°
6.60 ± 0.05
3.88 ± 0.05
1.54 ± 0.05
1.56 ± 0.05
31.54 ± 0.05
2.45 ± 0.05
34.63 ± 0.05
13.20
17.70 ± 0.05
21.20 ± 0.05
4.60 ± 0.05
45.00° ± 0.03°
17.10 ± 0.05
20.60 ± 0.05
0.20 ± 0.05 5.00 ± 0.05
22.00 ± 0.10
Unit: mm
Dovetail Slot of Main Body
Dovetail Slot of Hand Grip
135.00°
6.60 ± 0.05
3.88 ± 0.05
1.54 ± 0.05
1.56 ± 0.05
31.54 ± 0.05
2.45 ± 0.05
34.63 ± 0.05
13.20
17.70 ± 0.05
21.20 ± 0.05
4.60 ± 0.05
45.00° ± 0.03°
17.10 ± 0.05
20.60 ± 0.05
0.20 ± 0.05 5.00 ± 0.05
22.00 ± 0.10
