DKS Standard - Model 6002, 6003 and 6400 S Wiring Diagrams

6400-065-C-1-09
39
1234567 1234567
Models 6002 , 6003 and 6400
1 Brown
2 Blue
3 Orange
4 Red
5 Yellow
6 Green
7 Green/Yellow
1
2
3
4
5
6
7
1
2
3
4
5
6
7
A
(Motor) Brown 1
(Motor) Blue 2
(Limit) Gray 3
(Slow Down) Purple 4
(Limit) Yellow 5
(Slow Down) Brown 6
(Common) 4 White Wires 7
1234567 1234567
Brown
White
White
Purple
Gray
Purple
Gray
Motor
6002
6003
6400
Yellow
Brown
(Limit) Yellow
(Slow Down) Brown
(Motor) Brown
(Motor) Blue
(Limit) Gray
(Slow Down) Purple
(Common) White
(Common) White
(Common) White
(Common) White
Yellow
Blue and Brown
Motor
Blue and Brown
A
A
Limit Assembly Limit Assembly
Limit Assembly Limit Assembly
Yellow
Green
Brown
Blue
Red
Green/Yellow
Orange
