6400-065-C-1-09
3
6400 SPECIFICATIONS
17”
12”
6”
Class of Operation Model 6400 - UL325 Class I
Type of Gate Residential Vehicular Swing Gates Only
Motor Torque 300 Nm
Voltage / Phase 115 VAC Single Phase Input Power – 24 VDC Operating Power
Current 3 Amps
Max Gate Weight 300 Lbs.
Max Gate Length 10 Feet
Cycles Per Hour 20 Per Hour with AC connected
Speed 90° in approximately 20 seconds
Entrapment Protection Primary - Inherent entrapment sensing system (Type A)
Secondary - Provision for connection of a non-contact sensor (Type B1)
2 5/8”
2”
2 1/4”
Underground Operator
7 3/8”
8 1/2”
19”
15 3/4”
8 1/2”
1 1/2” Dia. Plastic
Drainage Pipe
(Not Supplied)
Pivot
Point
Linking Arm
Pivot
Point
Manual
Release
Manual
Release
Drive
Arm
Locking
Bracket
Linking Arm
To Next Page
