Maintenance Section
108
Torques for Taperlock studs
Thread Size
Inch
Standard Taperlock Stud
Torque
N·m
1
lb·in
1/4 8±3 6±2
5/16 17±5 13±4
3/8 35 ±5 26±4
7/16 45±10 33±7
1/2 65±10 48±7
5/8 110±20 80±15
3/4 170±30 125±22
7/8 260±40 190±30
1 400±60 300±45
1 1/8 500±70 370±50
1 1/4 650±80 480±60
1 3/8 750±90 550±65
1 1/2 870±100 640±75
1
1 Newton meter (N·m) is approximately the same
as0.1 kg·m.
Torque for Metric Fasteners
NOTICE
Be very careful never to mix metric with U.S.
customary (standard) fasteners. Mismatched or
incorrect fasteners will cause lift truck damage or
malfunction and may even result in personal injury.
Original fasteners removed from the lift truck should
be checked for any damages and kept for
reassembly whenever possible. If new fasteners
are needed, they must be of the same size and
grade as the ones that are being replaced.
The material strength identification is usually shown
on the bolt head by numbers.(8.8, 10.9, etc.) The
following chart gives standard torques for bolts and
nuts with Grade 8.8.
For mounting torques of main parts, Please refer to
Service manual for detail.
NOTE: Metric hardware must be replaced with
metric hardware. Check parts book for
proper replacement.
METRIC ISO2 THREAD
Thread Size
Metric
Standard Torque
N·m
1
lb·in
M6 12±4 9±3
M8 25±7 18±5
M10 55±10 41±7
M12 95±15 70±11
M14 150±20 110±15
M16 220±30 160±22
M20 450±70 330±50
M24 775±100 570±75
M30 1600±200 1180±150
M36 2700±400 2000±300
1
1 Newton meter (N·m) is approximately the same
as 0.1 kg·m.
2
ISO-International Standard Organization.
