Maintenance Section
150
7. Check for oil leaks.
8. Retract all cylinders.
9. Turn the key switch to OFF.
10. Maintain the oil level to the FULL mark on the
breather / dipstick. Add oil if necessary.
Steer Wheel Bearings -
Reassemble
Park the lift truck level with the forks lowered,
parking brake engaged, and directional control
forward/reverse switch in NEUTRAL.
1. Lift the steer wheels off the ground. Place
stands or blocking under the frame and steer
axle to support the lift truck.
2. Remove the hub cap which is pressed into the
wheel hub.
3. Straighten the lockwasher tangs.
