Operation Section
87
Operating Techniques
NOTE: The photographs and line art used in the following Operating Techniques, are typical examples and
may not apply to your particular lift truck.
Inching into Loads
1. Move the lift truck slowly forward into position
and engage the load. Lift truck should be
square with load. The forks should be spaced
evenly between pallet stringers and as far apart
as the load will permit.
2. Move the lift truck forward until the load touches
the carriage
WARNING
The forklift truck must not be used to push
loads or other vehicles.
Only the moving equipment supplied or the rear
hook for towing must be used.
Lifting the Load
1. Lift the load carefully and tilt the mast back a
short distance.
2. Tilt the mast further back to cradle the load.
3. Operate the lift truck in reverse until the load is
clear of the other loads.
4. Lower the load to the travel position before
turning or traveling.
To Next Page
