Operation Section
47
Front and Rear Floodlights Switch
Located on the right side of the instrument panel.
OFF – Push the switch down to turn off the
headlamp and rear lamp /rear.
Headlamp – When the switch is pushed upwards,
the headlamp turns on at the first position.
Headlamp/Rear lamp – When the switch is pushed
upwards, the headlamp and rear lamp turn on at
the second position The rear lamp is an option.
Horn Button
Located in the center of the steering wheel.
Push in on the horn button to sound the
horn.
Tilt Steering Column
Located on the lower front of the steering column.
To adjust the steering column, raise the handle(1)
and move the steering column to the desired
position. Release the handle and the steering
column will remain in the desired position.
Seat Adjustment
Adjust the seat at the beginning of each shift or
when changing operators.
Adjust the seat to allow full travel of all pedals with
the operator seated against the seat back.
The seat must be adjusted with the operator seated.
Move the lever to adjust the seat forward or
backward. Release the lever. Move the seat slightly
to lock it.
