NOMENCLATURE
1.4
©COPYRIGHT 2006, Heil Environmental
ISSUED JANUARY 2006
IN-CAB LOCATON
OF PTO OR PUMP
CONTROLS
SIDE ACCESS
DOOR
BODY
TAILGATE
(UPPER & LOWER
PACKER PANEL
LOCATIONS)
TAILGATE
CONTROLS
(LOCATED ON
OPPOSITE SIDE
OF BODY.)
TAILGATE
CLAMPS
EJECTOR PANEL
AND CYLINDER
LOCATION
TAILGATE AND
EJECTOR
CONTROLS
LOCATION
PTO OR FRONT
MOUNT PUMP
LACATIONS
