Dover HEIL DuraPack 5000 - Quick Reference - Parts Guide

QUICK REFERENCE PARTS GUIDE
DESCRIPTION PART NO.
CYLINDERS:
EJECTOR – 18 YD BODY……………….………..1-6463
EJECTOR – 20 YD BODY………………….……..1-6464
EJECTOR – 25 YD BODY....................................1-6427
EJECTOR – 27 YD BODY................…................1-6426
EJECTOR – 32 YD BODY....................................1-6421
OUTSIDE (upper panel)..…………………………1-6610
INSIDE (lower panel)..…………………………….1-6611
TAILGATE RAISE............…………………………1-4880
ROLL BAR...........................................................1-4105
REEVING.............................................................1-6061
ARM MECHANISM..............................................1-4283
VALVES:
UNDERBODY....................................................31-3285
MAIN RELIEF (set @ 2500 PSI).....................31-2979
INLET.........................................................31-3285-01
VALVE SECTIONS
EJECTOR...............................................31-3285-02
TAILGATE...............................................31-3285-04
TAILGATE (SECONDARY).............31-6269-02,03 or 04
BLADE BACK-OFF RELIEF (set @ 3900 PSI).....31-3245-08
AUX. PORT RELIEF (set @ 1400 PSI)...........31-3242
VALVE SECTIONS
TAILGATE...............................................31-3544-06
ARM, WINCH,ROLLBAR,REEVING.............31-6267
EJECTOR UNLOAD...........................................31-6272
REGENERATIVE………………………………....31-6285
FILTER .…………..………………………………..75-0912
12,000 LB. WINCH MOTOR...............................219-1879
SEAL KIT NO.
272-4881
272-4881
272-4880
272-4880
272-4884
1-6610-007
1-6611-004
272-0938
272-0958
272-0989
272-0966
31-3285-48
207-6103
31-3285-41, 31-3285-26,
31-2940-06
31-32385-41, 31-3285-26,
31-2940-06
272-3861 (spool)
372-1434 (spool)
075-0912-001
(ELEMENT)
219-1878-21
Printed in U. S. A. ISSUED JANUARY 2006
©COPYRIGHT 2006, Heil Environmental
1.5
