Supplement for Infinity Delta Series Software
44 Supplement – Infinity
®
Delta Series Software VF10.1
Source dialog
When Delta detects both a mainstream and SCIO device are connected, the Source dialog appears.
The user must select the preferred device from the dialog, or disconnect either the mainstream or SCIO
device to exit the screen lock.
To select the source of CO2 from the Source dialog:
– Dial to Mainstream or SCIO accordingly and click to select it.
To select the source of CO2 manually:
1 Click the CO2 or CO2* parameter box (whichever is active) on the Main screen.
2 Click Source.
3 Dial to Mainstream or SCIO accordingly and click to select it.
Duplicate Device Connected
The message Duplicate Device Connected appears when multiple CO2* devices are connected to the
monitor (for example, a Dräger ventilator and a Scio Four module that is connected to the IDS).
In addition to the message, the etCO2* parameter menu appears. You can select the desired CO2* device
(as described in the Quick Reference Table). Or, you can physically disconnect the undesired CO2*
device.
A label in the upper left corner of the etCO2* waveform identifies the CO2* device that is providing
information to the user.
Disconnect Duplicate etCO2 Pods
When Delta detects any two or more of the devices listed below are connected, the message Disconnect
Duplicate etCO2 Pods appears:
– Mainstream
– Microstream
– etCO2 + Respiratory Mechanics Pod
– etCO2 Pod
– etCO2 Cartridge
NOTE
Delta continues to monitor the first device connected (mainstream or SCIO) until it is disconnected or
the alternate device is selected from the Source dialog.
NOTE
CO2* devices include the Dräger Scio Four modules or a device with etCO2* capabilities (e.g.,
ventilator, anesthesia machine) connected through MIB.
