The menu » Settings «
76
Sensor test
This group contains the setting functions for the sensor selftest.
These functions can be used only if the Polytron 7000 transmitter is equipped
with the Sensor Dongle 83 17 619 or the Sensor Diagnostic Dongle 83 17 860,
see page 29.
– Sensor test setting
— This function can be used to activate or reactivate the sensor selftest.
● Select the menu items « Settings «, « Sensor « and « Set sensor test « in this or-
der, pressing the » « key after each selection.
● Use the » « and » « keys to select « Enable « or « Disable « and press the
» « key to activate.
— If the sensor selftest is enabled, the transmitter continually tests the sensor in or-
der to ensure reliable operation. If the sensor does not pass the selftest, a suitable
warning or fault is generated.
– Sensor self-test
— This function is used to start the sensor self-test.
● Select the menu items « Settings «, « Sensor «, » ECXX « and « Sensor self-test «.
● If a sensor self-test can be executed (depending on sensor or device status): Use
» « to select » Start sensor self-test «, then press » « button to start.
— After a few seconds the result is indicated in the display.
To terminate the function:
● Select » Back to menu « and press the » « key.
– Sensor lock
— This function is used to enable or disable the sensor lock.
● Select the menu items » Settings «, » Sensor « , « EC–O
2
« and » Sensor lock «
in this order, pressing the » « key after each selection.
● Select » Enable « or » Disable « and press the » « key to activate.
Enable = The transmitter will accept a new sensor only if it has the
same Part No. (=Dräger Order No.) as the old sensor and
thus the same sensor type.
Disable = The transmitter will accept other sensor types. In this case,
the transmitter uses the default settings for the new sensor,
which means that the transmitter configuration will be
changed.
OK
M
OK
M
OK
OK
OK
OK
