Tank filler plug
Opening
flap (1) and the active or passive key in the
lock. Turn the key clockwise by 1/4 of a turn to release
the lock.
the plug (2).
Closing
Close the plug (2) with the key and push it
down into its seat. Remove the key and close flap (1)
protecting the lock.
Note
Plug can only be closed when key is
refuelling, always make sure that the plug
is in place and closed.
Electric filler plug opening (option)
The electric plug (2, Fig 144) opens every
for 60 seconds, working lever (1, Fig 143)
present on plug.
Fig 143
Fig 144
191
