Instrument panel
(Dashboard)
Instrument panel
1) LCD display.
2) NEUTRAL LIGHT N (GREEN).
Comes on when in neutral position.
3) FOG LIGHT WARNING LIGHT (GREEN).
It turns on when the fog lights are activated.
4) HIGH BEAM LIGHT
(BLUE).
It turns on to indicate that the high beam lights are
on and when the flasher is activated.
5) FUEL WARNING LIGHT
(AMBER YELLOW).
Comes on when fuel is low and there are about 4
litres of fuel in the tank.
6) TURN INDICATOR LIGHTS
(GREEN).
Illuminates and flashes when the turn indicator is in
operation.
7) ENGINE OIL PRESSURE LIGHT
(RED).
Comes on when engine oil pressure is too low. It
must turn on at "KEY-ON", but must turn a few
seconds the engine has It may
come on when the engine is hot, however, it should
go out as the engine revs up.
If the ENGINE OIL light stays ON, stop the
engine or it may severe damage.
8) DTC WARNING LIGHT
This light indicates DTC system enabling/disabling
status.
- Light DTC enabled and functioning;
- Light ON flashing: DTC enabled, but with
degraded
- Light steady ON: DTC disabled and/or not
functioning due to a fault in the control unit.
9) "ENGINE DIAGNOSIS - MIL" LIGHT
(AMBER
YELLOW).
It turns on in the case of "engine" errors that in some
cases will lock the engine.
10) ABS LIGHT
(AMBER YELLOW).
