Brake calliper make: BREMBO, radially-mounted
monobloc callipers.
Calliper piston diameter: 32 mm (1.26 in).
Number of pistons per calliper: 4.
Front brake type: M4.32 B (4x32).
Friction material: BRM11E HH.
Brake master cylinder type: radial.
Cylinder Ø: 18 mm (0.71 in).
REAR
With fixed drilled steel disc.
Disc diameter: 265 mm (10.43 in).
Rear brake disc thickness: 6 mm (0.24 in)
Disc thickness (maximum wear): 5.4 mm (0.21 in).
Braking 210 sq.
cm (32.55 in
2
).
Hydraulically operated by a pedal on RH side.
Brake calliper make: BREMBO, floating 2-piston
calliper with cornering ABS as standard.
Fixed, 28 mm (1.10 in) diameter 2-piston calliper.
Friction material: TT 2182 FF.
Brake master cylinder type: PF 2x28 D.
The brake fluid used in the brake system is
corrosive.
In the event of accidental contact with eyes or skin,
wash the area with abundant running water.
Transmission
Hydraulically-controlled slipper self-servo wet
multiplate clutch.
Drive is from engine to gearbox primary
via spur gears.
Front chain sprocket/clutch gearwheel ratio: 33/61.
Spur gears, 1.84:1 ratio.
6-speed gearbox with constant mesh gears, gear
change pedal on side of motorcycle.
Gearbox output sprocket/rear chain sprocket ratio:
15/43.
Total gear ratios:
1
st
gear 37/15
2
nd
gear 30/17
3
rd
gear 28/20
4
th
gear 26/22
5
th
gear 24/23
6
th
gear 23/24
279
