Ducati MULTISTRADA 950 - Adjusting the Front Fork

Adjusting the front fork
The front fork used on this motorcycle has rebound
(return), compression and spring preload
adjustment.
Adjustment is done by external screw adjusters:
1) for rebound adjustment;
2) to adjust the preload of the inner springs;
3) to adjust the compression damping.
Position the motorcycle on its side stand so that it is
stable.
Turn adjuster (1) at the top end of the RH fork leg
with a suitable screwdriver to adjust rebound.
Turn adjuster (3) at the top end of the LH fork leg
with a suitable screwdriver to adjust compression.
By turning adjuster screws (1) and (3) you will hear
some clicks; each click corresponds to a damping
 The  damping  is obtained
with the adjuster turned fully clockwise to the "0"
position.
By turning counter clockwise  from this
position, count the clicks that will correspond to
positions "1", "2" etc.
S
S
E
N
T
H
H
2
1
Fig 180
S
S
H
H
3
Fig 181
217
