Charging the
Before charging the it is best to remove it
from the motorcycle.
Remove the rider seat, loosen screw (1) and remove
the mounting bracket (2). Loosen the screws (3),
remove the positive cable (4) and (ABS) positive
cable (5) from the positive terminal and the negative
cable (6) from the negative terminal always
from the negative one (-) then remove the by
pulling it up.
The gives explosive gases; never
cause sparks or allow naked flames and
near the When charging the ensure
that the working area is properly ventilated.
Charge the in a ventilated room.
Connect the charger leads to the
terminals: the red one to the positive terminal (+),
the black one to the negative terminal (-).
Make sure the charger is OFF when you
connect the to it, or you might get sparks at
the terminals that could ignite the gases
inside the cells. Always connect the red positive (+)
terminal first.
Fig 201
241
