the passenger seat
Position the passenger seat (2) on the rear subframe
by tab (3) into seat (8) inside of the tool
Push the passenger seat (2) downwards to block pin
(9) into the seat lock.
Make sure the passenger seat (2) is properly
fastened by moderately pulling it up.
Take key out of the lock.
Fig 151
195
