The main fuse (C) of 30A is positioned on the
solenoid Remove the fuse cap to reach it. A
blown fuse can be identified by breakage of the inner
filament (F).
Switch the ignition key to OFF before replacing
the fuse to avoid possible
Never use a fuse with a rating other than
specified. Failure to observe this rule may damage
the electric system or even cause fire.
Fig 226
Fig 227
285
