LAP BASIC with GPS module
If there is a GPS module on the motorcycle, the timer
and stop is managed automatically by the
instrument panel activating the function.
Here are the screens for Track Info Mode (Fig 77) and
Track Evo Info Mode (Fig 78).
The display shows GPS symbol (D) to timer
and lap number.
When lap one press the FLASH (4) to
the timer: both timer (that and lap
number (that will become “Lap 01”) will flash for 1
second. At the same time, the instrument panel
stores finish-line position via the GPS control unit
and activates the symbol (E): all the following laps
will be directly recorded by the instrument panel and
the FLASH (4) is no longer used for the timer
function.
Any time the bike reaches the finish-line position as
recorded by the instrument panel, the just recorded
time and lap will flash for one second and remain
displayed for another 5 seconds; this period of
time the function displays again the timer and lap
progressive number.
For each lap, the following data are stored:
190
01’35.27
km/h
Lap 1/60
4
11:34
A.M.
SPORT
RPM X 1000
Gear
DWC 3
DTC 3
DSC 2
LO HI
SETTING MENU
TRIP 1
TOT km
1245
0.0 km
D E 14
32
Fig 77
Fig 78
124
