Position the cover (7) fastening the tighten
the screw (6).
Position the ignition switch cover (4), operating from
the front and paying to the inner tabs (B)
connected to the side fairing, positioned on both
sides.
Tighten the two side (3) and upper (5) screws
retaining the ignition switch cover (4).
Fig 194
Fig 195
248
