Service Manual for Flexible Batch Broiler Units
Product Stop Bracket Adjustment
The Product Stop Bracket sits above the cook chain
on the back wall of the cook cavity. It prevents
product from being loaded and pushed up on top
of the cook chain links.
1. Remove the Rear Panel and Element Cover
Panel. Refer to the COVERS and PANELS
section of the manual.
2. Loosen three nuts which secure the Product
Stop Bracket and adjust bracket up or down
as needed.
Product Stop Bracket
Loosen nuts
Product Stop Bracket Adjustment
