CONTROL DIAGNOSTICS
The Broiler Control consists of two programming modes and two diagnostic modes. To enter any of these
4 modes, it is required to rst hold down the ENTER button for a few seconds until CODE is displayed.
Then enter the 4 digit passcode provided below and press ENTER.
Programming
1. Recipe related programming (Refer to Owner’s Manual)
Passcode: 1 8 2 7
2. Broiler functionality programming (Refer to Owner’s Manual)
Passcode: 3 6 4 5
Diagnostics
1. Diagnostic Test
Passcode: 3 4 2 4
After entering the code and pressing ENTER, DIAG will be displayed and then
the display will show 8888.
The following options are available:
a) Pressing the key will run the Conveyor Drive Motor.
NOTE: Do not run the Conveyor Drive Motor for more than 6 seconds at a time. It will overheat.
Pressing the key a second time will energize the Cook Light.
b) Pressing the key once will initiate an Element Diagnostic test with
the TOP ELEMENTS ON only.
a. S1 = H1 Current
b. S2 = H2 Current
c. S3 = H3 Current
c) Pressing the key a second time will initiate an Element Diagnostic test with
the BOTTOM ELEMENTS ON only.
a. S1 = H4 Current
b. S2 = H5 Current
c. S3 = H6 Current
d) Pressing the key a third time will initiate an Element Diagnostic test
with ALL ELEMENTS OFF.
a. S1 = H1 & H4 Current
b. S2 = H2 & H5 Current
c. S3 = H3 & H6 Current
e) Pressing the key a fourth time will go back to the home screen, 8888.
f ) Pressing the ENTER button from here will exit Diagnostic mode.
