Symptom Cause Remedy
Display shows “triP”
High Limit
Thermostat
Test continuity on Thermostat located on
Relay Heat Sink.
Cooling Fan
Ensure Cooling Fan runs when On / Off
Switch is turned ON.
Cooling
obstruction
Clean Cooling Fan and any other item which
may not be allowing Relay Heat Sink to
dissipate heat effectively.
Display shows “Prob”
Temperature
Probe
Test continuity for open or shorted
Temperature Probe.
Cook Chain does not move /
Runs all the time
Discharge Chute Discharge Chute is not properly in place.
Cook Chain
obstruction
Cook Chain is catching on another item, i.e.
ash scraper, loader ramp, ame arrestor. May
require adjustment of Ash Scraper Bracket.
Cook Chain not
properly adjusted
It may be necessary to install shims behind or
underneath shaft bearings to ensure proper
position and tension of the cook chain.
Loose Drive Chain
Deection of Drive Chain should be
approximately 3/16”.
Loose Motor
Sprocket
When tightening, ensure motor sprocket
is orientated the same way as the shaft
sprocket.
Control
Ensure Control is signaling to energize the
Conveyor Motor Relay.
Solid State Relay
Ensure Conveyor Motor Relay is closing.
Replace Solid State Relay if Conveyor Motor
runs non-stop.
Conveyor Motor Test Conveyor Motor for fault.
Capacitor Test Conveyor Motor Capacitor for fault.
