Duplo DBM-600T User Manual

6-6
Chapter 6 Appendix
Specifications when using the options
Model CALENDAR KIT
Paper size (Cover + inner sheets)
A3 SEF + A4 LEF, A4 SEF + A5 LEF, LGR SEF + LTR LEF
Paper quality Cover
Fine quality: 157 to 280 g/m²/42 to 74 lb
Art/coated paper: 157 to 280 g/m²/42 to 74 lb
Inner sheets
Fine quality: 80 to 160 g/m²/21 to 43 lb
Art/coated paper: 104.7 to 160 g/m²/28 to 43 lb
*When the number of inner sheets is 7 or more, cover paper with less than 200 g/m²/53 lb
cannot be used.
The number of
processable sheets
Cover: 1
Inner sheets: 3 to 12
The maximum
thickness of a set
that can be sent
Same as the specication of the main body
Processing speed 2,800 sets/hour A4 SEF 1 sheet + A5 LEF 3 sheets, A5 nish
2,400 sets/hour A3 SEF 1 sheet + A4 LEF 3 sheets, A4 nish
The minimum
distance from the
edge of paper to
the stitch
70 mm/2.76 inches
Limitations The maximum stitch pitch at normal processing: 312 mm/12.28 inches
The CALENDAR KIT cannot be used with the 4 STITCH KIT.
Fore-edge trimming is not available.
Model OFFSET TRIM KIT
Paper size When using the oset function
Width: More than 122 to less than 342 mm/4.80 to 13.47 inches
Length: Same as the specication of the main body
*The ratio of the width and length should be 1.5:1 or less.
When not using the oset function
Width: Same as the specication of the main bod
Length: Same as the specication of the main body
Oset amount 0 to 21 mm/0 to 0.83 inch
Adjusted manually. There is a limit depending on the paper size.
Others Same as the specications of the main body for paper quality, the number of processable
sheets, the maximum thickness of a set that can be sent, and the processing speed
When using the DBM-SSW or DBM-LSW, booklets may not be properly stacked depending on the paper
quality of a booklet and the number of sheets.
