2-7
Chapter 2 Basic Operation
5
Enter [2910] using the numeric keypad.
6
Press the key.
The value entered is conrmed and the paper size entry screen is displayed.
Stitching width
When a nished length is entered, the standard stitching width (center to center distance between the
two stitches) is displayed in the [3] box.
[144.0] is displayed in this example.
To change the value, press the [3] box and enter a desired value using the numeric keypad.
If the value you entered falls on the stitch prohibited area, the folding knife and a stitch coincide
and the folding position may slightly change. We recommend that you do not fine adjust a
stitching position and leave it as it is.
”4-4-1. Stitch and fold setting screen” (p.1-19)
Step4
Conrm the setting
1
Press the key.
The information registered in the memory No.
is saved and the [Main] screen is displayed.
2
Press the key for more than one
second.
According to the settings, the guides will move.
2-2. Setting the custom size
Example)
Memory used: No.1
Paper size: length x width 500 x 297 mm/ 19.69 x 11.69 inches
Finished size: 248 x 297 mm/9.76 x 11.58 inches
Binding: saddle stitch, 4 stitches
Folding: on
Trimming: fore-edge trimming 2 mm/0.08 inch, head/foot trimming (head: 1 mm/0.04 inch, foot: 2
mm/0.08 inch)*
* You can specify oset trimming when the OFFSET TRIM KIT (option) has been attached.
To Next Page
