Duplo DBM-600T User Manual

2-3
Chapter 2 Basic Operation
2. Setting the Control Panel
Make settings for a binding mode, paper size, trimming and others on the control panel. If you do not use
the default memory, select a memory number and make settings following the procedures below. All the
memories can be overwritten. It would be useful to register 20 types of settings you regularly use.
The default setting is as shown in the table below.
• When the machine is connected to the PC CONTROLLER, use the PC CONTROLLER to make settings.
You cannot make settings using this machine.
• You can make settings to prevent you from overwriting data.
• Information on memory No. 0
If you do not want to overwrite the default memory, you can save the setting you made in the
memory No. 0. The information saved in No. 0 is cleared once you turn o the power.
How to use No. 0
1) Select either one from the memories No. 1 to 20 and press the key.
2) Select the memory No. 0.
3) The detailed information on the memory you have selected in step 1) is displayed on the touch
panel.
4) Press the key.
5) Change the binding method.
6) Press the key again.
Memory
No.
Paper size
Stitch Fold
mm inch
Standard
size
1 420 x 297 16.54 x 11.69 A3 Saddle stitch Fold on
2 297 x 210 11.69 x 8.27 A4 Saddle stitch Fold on
3 210 x 297 8.27 x 11.69 A4 LEF Side stitch Fold o
4 210 x 148 8.27 x 5.83 A5 Saddle stitch Fold on
5 450 x 320 17.72 x 12.60 A3SR Saddle stitch Fold on
6 320 x 225 12.60 x 8.86 A4SR Saddle stitch Fold on
7 240 x 120 9.45 x 4.72 CD Saddle stitch Fold on
8 515 x 364 20.28 x 14.33 B3 Saddle stitch Fold on
9 364 x 257 14.33 x 10.12 B4 Saddle stitch Fold on
10 257 x 364 10.12 x 14.33 B4 LEF Side stitch Fold o
11 257 x 182 10.12 x 7.17 B5 Saddle stitch Fold on
12 182 x 257 7.17 x 10.12 B5 LEF Side stitch Fold o
13 431.8 x 279.4 17.00 x 11.00 LGR Saddle stitch Fold on
14 355.6 x 215.9 14.00 x 8.50 LGL Saddle stitch Fold on
15 215.9 x 355.6 8.50 x 14.00 LGL LEF Side stitch Fold o
16 279.4 x 215.9 11.00 x 8.50 LTR Saddle stitch Fold on
17 215.9 x 279.4 8.50 x 11.00 LTR LEF Side stitch Fold o
18 266.7 x 184.1 10.50 x 7.25 EXEC Saddle stitch Fold on
19 184.1 x 266.7 7.25 x 10.50 EXEC LEF Side stitch Fold o
20 215.9 x 139.7 8.50 x 5.50 STMT Saddle stitch Fold on
