iv
Safety Precautions
Safety devices
[1]
[2]
[1]
[4]
[3]
No. Name Function
[1] Emergency stop switch Press this switch to stop the machine in emergencies. Turn the pressed
switch to the right to release it. While pressed, the machine will not
start and its moving parts will also not move.
[2] Top cover interlock switch L The switch is associated with the cover and it activates the interlocking
system which consists of the protective guards, the electrical circuit
and the actuators.
The hinged or sliding cover, which can be manually opened or closed,
works as an interlocking guard associated with the electrical drive
circuit so that the hazardous moving parts do not move while the
cover is opened.
[3] Top cover interlock switch R
[4] Top cover interlock switch
