1-14
Chapter 1 Before Operation
No. Name QTY Use
[4] Hexagonal wrench (*) 1 Used for removing the stitcher head. For information on how to use this,
refer to the stitcher head instruction manual.
[5] Positioning guide 1 Used for attaching the stitcher head. For information on how to use this,
refer to the stitcher head instruction manual.
[6] Longnose pliers (*) 1 Used for setting the wire on the stitcher head.
(p.4-5)
[7] Adjusting handle 1 Used for mounting and adjusting the wire.
(p.3-5)
(p.4-7)
[8] Oiler 1 Used for oiling the stitcher head.
(p.4-8)
[9] Guide 1 unit 2 Used when a booklet is damaged.
(p.2-43)
[10] Guide 2 unit 2
[11] Guide 3 unit 2
[12] Angle F unit 1
[13] Angle B unit 1
[14] Paper guide 1 Used for side stitching.
(p.2-16)
[15] Paper receiving guide F 1 Used when paper is misaligned in the width direction on the paper
receiver during side stitching. (magnet type)
(p.2-41)
[16] Paper receiving guide B 1
[17] Paper guide bracket 1 Used when paper is not neatly stacked on the paper receiver during
side stitching. (magnet type)
(p.2-41)
[18] Page insertion rollers 1 Replace the ejection rollers with these rollers for page insertion
operations.
(p.2-41)
[19] Page insertion guide 1 Used for page insertion.
(p.2-16)
[20] Power cord 1 For North America
[21] Power cord 1 For EU
[22] Instruction manual 1 This manual
[23] Safety Guide A 1 Contains information for correct and safe use of this machine.
[24] Stitcher head instruction
manual
1 CD-ROM manual for the stitcher head
(*) Do not use these tools for purposes other than instructed in this manual or the stitcher head instruction
manual.
3-2. Accessories for the DBM-600T
[1] [3] [4][2]
No. Name QTY Use
[1] L-wrench (*) 1 Used to loosen or tighten the screw of the press angle unit.
(p.2-44)(p.2-45)
[2] Scrap box 1 Ocuts are ejected to this box.
(p.4-3)
[3] Power cord 1 For North America
[4] Power cord 1 For EU
(*) Do not use these tools for purposes other than instructed in this manual.
To Next Page
