Chapter 1 Before Operation
No. Name Function
[4] Control panel Use this to operate the machine.
(p.1-15)
[5] Emergency stop switch Press this switch to stop the machine in emergencies. Turn the pressed
switch to the right to release it. While pressed, the machine will not
start and its moving parts will also not move.
[6] Top cover L Cover for ensuring user safety. This machine will not operate if open.
[7] Fold misalignment adjustment Adjusts the angle of the folding side guides.
(p.2-31)
[8] Fold misalignment adjustment knob
screw
Secures the angle of the folding side guides.
(p.2-31)
[9] Paper receiver knob screw Secures the position of the paper receiver.
(p.2-17)
[10] Paper receiver stopper Stops side-stitched or corner-stitched booklets on the paper receiver.
(p.2-17)
[11] Paper receiver Receives side-stitched or corner-stitched booklets.
(p.2-17)
[12] Paper receiver booklet holder Holds down the booklets ejected to the paper receiver.
[13] Handle Used to pull the paper receiver.
[14] Paper receiver full loading sensor
height adjustment
Secures the height of the paper receiver full loading sensor.
[15] Power inlet Connector for the power cord.
