2009 DURATECH TUB GRINDER OPERATING INSTRUCTIONS

BATTERY DISCONNECT SWITCH

The battery disconnect switch is used to connect and disconnect the main battery cable to the machine. When the

machine is not in use, it should be disconnected.

Battery disconnect switch
