Designing a Layout
Barcode Object Properties
Symbology Select the type of barcode to add to your label.
Barcode data Enter the text you want to use to create the barcode.
Function as variable
object
Select this check box to create the barcode using variable
text.
Linked to object
Select the reference name for an object on your label that
contains the data to create the barcode. This option is
necessary if you have more than one variable object on the
label.
Alignment
Left - Left align the barcode within the object.
Center - Center the barcode within the object.
Right - Right align the barcode within the object.
Barcode size
Select a size for your barcode.
Make sure that the barcode size you choose will work
with your application.
Human-readable text
None - Do not print the human-readable text.
Above - Place the barcode text above the barcode.
Below - Place the barcode text below the barcode.
Font - Change the font for the human-readable text.
Adding a Counter Object
You can automatically and sequentially number labels by placing a Counter object on the
label layout.
You can define text you want to appear before and after the counter numbers. You can also
specify the starting number, the increment to be used for counting (1, 2, 10, and so on), the
minimum width of the numbers, and include leading zeros.
You can change the font settings for the numbers and text, and change the horizontal and
vertical alignment of the text and numbers. You can also print the counting information in
vertical format and create mirror images of the counter information on the labels.
The labels are automatically numbered according to your specifications when you print
them. The current number and other settings appear on the label displayed in the Edit area.
To add a Counter object
1. Select the Insert tab.
2.
Double-click Counter.
A new Counter object containing 001 is added to your label.
3. Right-click the object, and then choose Properties.
4. Make any desired changes in the Counter Object Properties dialog box, and then click
OK.
5. Move and resize the object as necessary.
To resize an object, select the object and drag a handle on the bounding box.
56
