DynaGen GSC400 Series User Manual

75 of 105
Shorted Sender Disable
Open Sender Disable
Units Percentage
Warning Level 10%
Failure Level 5%
Fuel In Basin
Input Pin Disable
Signal Source Switch
Bypass Delay 11 Seconds
Switch Setting SW Closed = Fail
Shorted Sender Disable
Open Sender Disable
Units Percentage
Warning Level 2%
Failure Level 5%
Low Engine
Temperature
Input Pin Disable
Signal Source Switch
Bypass Delay 10 Seconds
Switch Setting SW Closed = Fail
Shorted Sender Disable
Open Sender Disable
Units Fahrenheit
Warning Level 10ºF
Spd Sensing
Signal Source Generator Output
Rated Freq 60 Hz
Rated RPM 1800 RPM
Over Speed Warn 1950 RPM
Over Speed Fail 2050 RPM
Under Speed Warn 1650 RPM
Under Speed Fail 1550 RPM
AC Frequency
Frequency Disconnect 22 Hz
Over Freq Warn 70 Hz
Over Freq Fail 75 Hz
Under Freq Warn 50 Hz
Under Freq Fail 45 Hz
A/C Voltage
Voltage Source Enable
Voltage Display Line-Neutral
Voltage Group Group #1 (Single)
Over Volt Warn 1 250 VAC
Over Volt Fail 1 260 VAC
Under Volt Warn 1 230 VAC
Under Volt Fail 1 220 VAC
Over Volt Warn 2 220 VAC
Over Volt Fail 2 230 VAC
Under Volt Warn 2 195 VAC
Under Volt Fail 2 185 VAC
Over Volt Warn 3 500 VAC
Over Volt Fail 3 520 VAC
Under Volt Warn 3 460 VAC
Under Volt Fail 3 440 VAC
Over Volt Warn 4 630 VAC
