DynaGen GSC400 Series User Manual

88 of 105
(this bit will flash)
bit10: AC under voltage warning
bit11: AC over voltage warning
bit12: AC over current warning
bit13: Fuel in basin warning
bit14: Voltage Regulator Digital Output
feature is on.
bit15: Low engine temperature warning
40084
bit0: Backlight is on
bit1: Auxiliary warning
bit2 : Maintenance is required
bit3: System is OK (definition: no
warning, including not in auto warning)
bit4: Common fault 1 digital output
feature (warning and failure)
bit5: Common fault 2 digital output
feature (warning and failure)
bit6: Dummy load digital output feature
bit7 : reserved
bit8 : Over current latch (AC Current
feature)
bit9: User configurable warning 1 digital
output feature
bit10: User configurable warning 2
digital output feature
bit11: User configurable failure1 digital
output feature
bit12: User configurable failure 2 digital
output feature
bit13 to bit15: (Reserved)
40085
bit0 to bit4: (Reserved)
bit5 : Low oil level failure
bit6: Low air pressure failure digital
input
bit7: Low hydraulic failure digital input
bit8: Auxiliary input failure
bit9: Low battery level failure
bit10: High battery level failure
bit11: AC over voltage failure
bit12: AC under voltage failure
bit13: AC over current failure
