89 of 105
bit14: J1939 Loss of ECM failure
bit15: EPS load failure
40086
(f/w
versions
2.02 and
above)
bit0: PGN 61444 EEC1 not available
(engine speed)
bit1: PGN 65263 Fluid level not
available (oil pressure)
bit2: PGN 65262 Engine temperature
not available
bit3: Emergency stop active
bit4: Low battery voltage during
cranking active
bit5: Battery charger fault active
bit6: System not ready active
bit7: Low oil level warning active
40090 GSC400 hardware
version number
1.00 ~ 9.99 R
40091 GSC400 firmware
version number
1.00 ~ 9.99 R
Version format is “X.YY” ; Decimal
format where X represents a number
from 1 – 9 and is stored in the high byte
of 40090. YY represents a decimal
number from 00 to 99 and is stored in the
lower byte of 40090.
40092 ~
40095
GSC400 serial
number
4 to 7
characters
R
The serial number is stored in 7 digit
decimal format with the high byte of
register 40092 containing the high MSB
and the low byte of register 40095
containing the LSB. Unused characters
are stored as zeros. For example serial
number 0012450 would be stored as
follows:
40092 MSB = 0
40092 LSB = 0
40093 MSB = 1
40093 LSB = 2
40094 MSB = 4
40094 LSB = 5
40095 MSB = 0
40095 LSB = NOT USED
2. START/STOP CONTROL AND COMMAND
Start/Stop registers are polled by the controller every 250mS.
