90 of 105
SYSTEM DISABLE 0x5DA2
(23970)
W
When 0x5DA2 is written to address
40098 this places the controller in the
OFF mode (System disabled). The
register is read in all controller operating
modes (Running, Auto, Failure,
Menu/sleep modes). CAUTION – when
received in the Running mode the
controller immediately goes to the OFF
mode (no cool-down is performed).
When received in failure mode this will
reset the system failure and revert to
the OFF mode.
SYSTEM ENABLE 0x5BA4
(23460)
W
When 0x5BA4 is written to address
40098 this places the controller in the
AUTO mode (waiting to start). The
register is read only in the OFF mode
of operation and ignored in all other
operating modes.
START 0x9768
(38760)
W
When 0x9768 is written to address 40098
this initiates an automatic start. This
register is only read in the AUTO
mode of operation and is ignored in
other modes.
STOP 0x57A8
(22440)
W
When 0x57A8 is written to address
40098 this initiates a shutdown/stop of
the equipment. This register is only
monitored when the system is running
(start signal received) and is ignored in
all other operating modes. When cool
down is enabled and a stop command
is received the controller will proceed
to the cool down mode then shutdown
equipment.
40098
REQUEST DM2 0xBB44 W
Send a request to controller for reading
the previous DTC codes. If the controller
read the previous DTC code success, the
data will be updated in the range of
40180 to 40244. This registers can hold
maximum 32 DTC code
3. SYSTEM CONTROL STATUS
