9000X AF Drives User Manual
MN04001004E
For more information visit: www.eaton.com 4-5
June 2009
Figure 4-3: Option Board A9 Jumper Location and Settings
Wiring Option Board A2
Figure 4-4: Option Board A2 Wiring Diagram
CMB and CMA Internally
Connected and Isolated
from Ground
X1 Jumper Setting
Analog Input 1 (AI1)
X2 Jumper Setting
Analog Input 2 (AI2)
X6 Jumper Setting
Analog Output 1 (A01)
X3 Jumper Setting
CMA and CMB Grounding
0 to 10V*
Voltage Input
-10 to 10V
Voltage Input
0 to 20 mA
Current Input
0 to 10V
(Differential)
Voltage Input
CMB Connected to Ground*
CMA Connected to Ground
CMB Isolated from Ground
CMA Isolated from Ground
* Designates Default Jumper Settings
0 to 20 mA*
Current Input
0 to 10V
Voltage Input
0 to 10V
(Differential)
Voltage Input
-10 to 10V
Voltage Input
0 to 20 mA
Current Output
0 to 10V*
Voltage Output
A
B
C
D
A
B
C
D
A
B
C
D
X1
X3
X2 X6
A
B
CD
A
B
CD
A
B
CD
A
B
CD
A
B
C
D
A
B
C
D
A
B
C
D
A
B
C
D
A
B
C
D
A
B
CD
26
25
24
23
22
21
RO1/1
RO1/2
RO1/3
RO2/1
RO2/2
RO2/3
R
L
Switching:
<8A / 24V DC
<8A / 250V AC
<0.4A / 125V DC
Continuously
<2 Arms
AC / DC
Basic Relay Board A2
