Eaton 9000X - Figure A-9: NEMA Type 1 and 12 with Flange Kit, FR4, FR5 and FR6; Table A-8: FR4, FR5 and FR6 with Flange Kit Enclosure Dimensions

9000X AF Drives User Manual
A-12 For more information visit: www.eaton.com
MN04001004E
June 2009
Figure A-9: NEMA Type 1 and 12 with Flange Kit, FR4, FR5 and FR6 Enclosure Dimensions
Table A-8: FR4, FR5 and FR6 with Flange Kit Enclosure Dimensions
Frame
Size Voltage
Approximate Dimensions in Inches (mm)
W1 W2 H1 H2 H3 H4 H5 D1 D2 Dia.
FR4 230V 5.0
(128)
4.45
(113)
13.27
(337)
12.8
(325)
12.9
(327)
1.18
(30)
.87
(22)
7.5
(190)
3.0
(77)
.27
(7)
480V
FR5 230V 5.67
(144)
4.7
(120)
17.0
(434)
16.5
(420)
16.5
(419)
1.4
(36)
.7
(18)
8.42
(214)
3.93
(100)
.27
(7)
480V
FR6 230V 7.67
(195)
6.7
(170)
22.0
(560)
21.6
(549)
21.9
(558)
1.18
(30)
.79
(20)
9.33
(237)
4.17
(106)
.25
(6.5)
480V
575V
W2
H1
H2
D2
H4
H5
H3
W1
Dia.
D1
