Manual CEAG CG-Controller for CG 2000/ZB-S 30080001458 (C) July 2016 www.ceag.de
7 Definitions of keys
Key
Menu
ENTER





Main meaning
•Ifmainscreen,switchtothemainmenuselection
•Switchtothe menu one level higher and accept the changes
•Confirm
•Selectmenuitem=open
•Exitinputandacceptthechanges
•Selectthemenuitemabove
•Selectthemenuitembelow
•Back
•Previouscursorposition
•Reducevalue
•De-activate
•Forward
•Nextcursorposition
• Increase value
• Activate
Table 1: Definitions of keys
Figure 5: Control panel
LEDs for
operation test fault
LCD display
memory card
LEDs for
communication
Alphanumeric keyboard
7 Definitions of keys
