9.10.9 Sending texts from the CG-Controller
to the device (Text SD)
The following message appears
while the texts from the device
are being read and saved to the SD:
If a fault is detected while reading from the SD, the following
message appears:
The following message appears when no memory card is insert-
ed in the CG 2000:
9.10.8 Reading texts from the device and
saving to SD (Text SD)
The following message appears
while the texts from the device
are being read and saved to the SD:
If a fault is detected while writing to the SD, the following
message appears:
Line Selection (submenu)
3 All devicesSD
4 Contr.cong.SD
5 Contr.cong.SD
6 Dev.cong.SD
7 Dev.cong.SD
8 TextSD
9 TextSD
Line Display
1 Device address 1
2 TextSD
3 Start n/y
4 Device name
Line Display
1 Luminaire name
2 TextSD
3 Percentage: 01%
4 Est. duration 220 min.
Operation:
Menu Cancel
(you may need to hold the key
down for longer)
Line Display
1
2 TextSD
3 SD write fault
4 Continue with
Operation:
Menu One menu level higher
 Confirm fault
Line Selection (submenu)
2 Delete logbook
3 All devicesSD
4 Contr.cong.SD
5 Contr.cong.SD
6 Dev.cong.SD
7 Dev.cong.SD
8 TextSD
9 TextSD
Line Display
1 Device address 1
2 TextSD
3 Start n/y
4 Device name
Line Display
1
2 TextSD
3 Percentage: 58%
4 Est. duration 55 min.
Operation:
Menu Cancel
(you may need to hold the key
down for longer)
Line Display
1
2 TextSD
3 SD read fault
4 Continue with
Operation:
Menu One menu level higher
Confirm fault
Line Display
1
2 TextSD
3 No SD in the device
4 Continue with
Operation:
Menu One menu level higher
Confirm fault
Operation:
Menu One menu level higher
Line 1:
Next device
Previous device
Line 3:
/ Yes / No
Confirm selection
Operation:
Menu One menu level higher
Line 1:
Next device
Previous device
Line 3:
/ Yes / No
Confirm selection
