Manual CEAG CG-Controller for CG 2000/ZB-S 30080001458 (C) July 2016 www.ceag.de
9 Menus
First, select a device in the first submenu. The device cannot be selected until all the information has
been read. After this, “Continue with“ appears in Line 4
9.7 Info device (submenu 2)
This is a list menu. You can scroll through it. If a * is displayed in the
last cursor position, this means that there are faults in this menu. The
device status and error messages appear under 6.1 and 6.2 according
to the lists as soon as there is a corresponding message from the cur-
rent device. A maximum of 4 states or faults are displayed.
9.6 «Info device» menu (submenu 1)
Line Selection (main menu)
1 Test menu
2 Block, reset
3 Info device ∕
4 Setup CG-Controller
5 Setup device
Operation:
Menu One menu level higher
 / Select the line
 Select the status display
Line Selection / display:
1 Circuit XX ↔
2 Status:
3 Status display
4 Circuit name
Operation:
Menu One menu level higher
 /  Selection in Line 1:
Next/previous circuit
Line Selection (status display)
1 Device status *∕
2 Failure reports *
3 Circuit-status *
4 Luminaire-status *
5 DLS/TLS/3PHW-status *
6 Charging-/bat.stat.
Operation (main menu):
 Flashing cursor = current
cursor position/selection
Menu Back to the main screen
 Cursor position lower
 Cursor position higher
 Select menu item (Enter)
9.7.1 Circuit status (device type=CG2000)
Possible status displays:
• OFF • Battery operation
• Mains operation • Normal operation
During communication with the system, «Please wait...» is displayed.
If there is an error, the faulty communication process is automatically
repeated. The read process then lasts somewhat longer.
Operation:
Menu One menu level higher
 /  Selection in Line 1:
Next/previous device
 Select device
Line Selection (device)
1 Device address XX↔
2 Device status
3 Device failure
4 Device name
Line Selection (status display)
1 Device status
2 Failure reports
3 Circuit-status ∕
4 Luminaire-status
etc.
9.7.2 Circuit status (device type=ZB-S)
Line Selection / display:
1 Read
2 Current assignment
3 
4 Please wait
Operation:
Menu One menu level higher
Line Selection (status display)
1 Device status
2 Failure reports
3 Circuit-status ∕
4 Luminaire-status
etc.
Line Selection / display:
1 SKU 1/7 circuit:1↔
2 Circuit-status:
3 Circuit failure
4 Circuit name
Operation:
Menu One menu level higher
 /  Selection in Line 1:
Next/previous SKU or
circuit
